Troubleshooting SiBE041213E
57 Service Diagnosis
4. Troubleshooting
4.1 Error Codes and Description
: Displayed only when system-down occurs.
Error Codes Description
Reference
Page
System
00
Normal —
U0
Refrigerant shortage 63
U2
Low-voltage detection or over-voltage detection 65
U4
Signal transmission error (between indoor unit and outdoor unit) 67
UA
Unspecified voltage (between indoor unit and outdoor unit) 69
Indoor
Unit
A1
Indoor unit PCB abnormality 58
A5
Freeze-up protection control / heating peak-cut control 59
A6
Fan motor (DC motor) or related abnormality 60
C4
Indoor heat exchanger thermistor or related abnormality 62
C9
Room temperature thermistor or related abnormality 62
Outdoor
Unit
E1
Outdoor unit PCB abnormality 70
E5
OL activation (compressor overload) 72
E6
Compressor lock 74
E7
DC fan lock 75
E8
Input overcurrent detection 76
EA
Four way valve abnormality 77
F3
Discharge pipe temperature control 79
F6
High pressure control in cooling 80
H0
Compressor system sensor abnormality 81
H6
Position sensor abnormality 82
H8
DC voltage / current sensor abnormality (35/42 class only) 84
H9
Outdoor temperature thermistor or related abnormality 85
J3
Discharge pipe thermistor or related abnormality 85
J6
Outdoor heat exchanger thermistor or related abnormality 85
L3
Electrical box temperature rise 87
L4
Radiation fin temperature rise 88
L5
Output overcurrent detection 90
P4
Radiation fin thermistor or related abnormality 85
