the screws and screw anchors are provided with the product,
check that they are suitable for the type of wall on which the
hood is to be fixed.
•Fixingthedecorativetelescopicflue:
Warning! If your appliance model features the lower
connector with a tab, before xing it in place bend the tab
inwards using a pair of pliers, as illustrated in gure 5, step1.
Arrange the electrical power supply within the dimensions of
the decorative flue. If your appliance is to be installed in the
ducting version or in the version with external motor, prepare
the air exhaust opening. Adjust the width of the support
bracket of the upper flue (Fig.3). Then fix it to the ceiling using
the screws A (Fig.3) in such a way that it is in line with your
hood and respecting the distance from the ceiling indicated
in Fig.2. Connect the flange C to the air exhaust hole using a
connection pipe (Fig.5). Insert the upper flue into the lower
flue. Fix the lower flue to the hood using the screws B provided
(Fig.5), extract the upper flue up to the bracket and fix it with
the screws B (Fig.3). To transform the hood from a ducting
version into a filtering version, ask your dealer for the charcoal
filters and follow the installation instructions.
•Filteringversion:
Install the hood and the two flues as described in the
paragraph for installation of the hood in ducting version. To
assemble the filtering flue refer to the instructions contained
in the kit. If the kit is not provided, order it from your dealer
as accessory. The filters must be applied to the suction unit
positioned inside the hood. They must be centred by turning
them 90 degrees until the stop catch is tripped (Fig.8).
USE AND MAINTENANCE
•We recommend that the cooker hood is switched on before
any food is cooked. We also recommend that the appliance is
left running for 15 minutes after the food is cooked, in order
to thoroughly eliminate all contaminated air.
The eective performance of the cooker hood depends on
constant maintenance; the anti-grease lter and the active
carbon lter both require special attention.
•Theanti-greaselter is responsible retaining the grease
particles suspended in the air, therefore it is subject to
clogging with variable frequency according to the use of the
appliance.
- To prevent the danger of possible res, at least every 2
months one must wash the anti-grease lters by hand using
non-abrasive neutral liquid detergents or in the dishwasher
at low temperatures and on short cycles.
- After a few washes, colour alterations may occur. This does
not give the right to claim their replacement.
•Theactivecarbonlters are used to purify the air that is
sent back into the room and its function s to mitigate the
unpleasant odours produced by cooking.
- The non-regenerable active carbon lters must be replaced
at least every 4 months. The saturation of the active charcoal
depends on the more or less prolonged use of the appliance,
on the type of kitchen and on the frequency with which anti-
grease lter is cleaned.
- Regenerable active charcoal lters must be washed by hand,
with non abrasive neutral detergents, or in the dishwasher at
a maximum temperature of 65°C (the washing cycle must be
complete without dishware). Remove excess water without
damaging the lter, remove the plastic parts, and let the mat
dry in the oven for at least 15 minutes approximately at a
maximum temperature of 100°C. To keep the regenerable
charcoal lter functioning ecient this operation must be
repeated every 2 months. These must be replaced at least
every 3 years or when the mat is damaged.
•Beforeremountingtheanti-greaseltersandtheregen-
erable active charcoal lters it is important that they are
completely dry.
•Cleanthehoodfrequently,bothinternallyandexter-
nally, using a cloth dampened with denatured alcohol or
neutral liquid detergents that are non abrasive.
•The lighting .system is designed for use during cooking
and not for the prolonged general lighting of the room. The
prolonged use of the lighting system signicantly decreases
the average duration of the bulbs.
•If the appliance is equipped with courtesy lights it is possible
to use them for general room lighting for a prolonged amount
of time.
•Attention: the non compliance with the hood cleaning
warnings and with the replacement and cleaning of the lters
entails risk of res. One therefore recommends keeping to the
suggested instructions.
•Replacinghalogenlightbulbs(Fig.6A):
To replace the halogen light bulbs B, remove the glass pane
C using a lever action on the relevant cracks.
Replace the bulbs with new ones of the same type.
Caution: do not touch the light bulb with bare hands.
•Replacingthehalogen/incandescentlamps(Fig.6B):
Only use lamps of the same type and wattage installed on
the device.
•Commands(Fig.9)mechanical the key symbols are ex-
plained below:
A = LIGHT
B = OFF
C = SPEED I
D = SPEED II
E = SPEED III.
•Commands(Fig.10)luminous the key symbols are ex-
plained below:
A = LIGHT
B = OFF
C = SPEED I
D = SPEED II
E = SPEED III
F = AUTOMATIC STOP TIMER - 15 minutes (*)
If your appliance does not have the INTENSIVE speed
function, press key E for two seconds and it will be activated
for 10 minutes after which it will return to the previously set
speed. When the function is active the LED ashes. To interrupt
it before the 10 minutes have expired press key E again.
By pressing key F for two seconds (with the hood switched
o ) the “clean air” function is activated. This function switches
the appliance on for ten minutes every hour at the rst speed.
As soon as this function is activated the motor starts up at the
rst speed for ten minutes. During this time key F and key
C must ash at the same time. After ten minutes the motor
switches o and the LED of key F remains switched on with
a xed light until the motor starts up again at the rst speed
after fty minutes and keys F and C start to ash again for ten
minutes and so on. By pressing any key for the exclusion of
the hood light the hood will return immediately to its normal
functioning (e.g. if key D is pressed the “clean air” function is
deactivated and the motor moves to the 2nd speed straight
away. By pressing key B the function is deactivated).
- 6 -
