ENGLISH

D-USE AND MAINTENANCE

* You are advised to start your device before starting cooking. Keep your device operating for 15 minutes after nishing cooking in order to

eliminate the food smell in the room.

* The oil lter will capture oil particles in the room and this lter might get clogged in accordance with your frequency of use. Comply with the

following instructions and clean your lter at least once in every 2 months in case of risk of re.

* Remove the lter from your device. Wash it using any type of natural detergent in water and rinse it thoroughly without leaving detergent

residues on it.

* Rinse with warm water and leave it to dry.

* You can wash your lter in your dish washer (max 40 C).

* The aluminum panel will change color after being washed a couple of times. This is totally normal and it will not cause any functional problem.

* The function of the carbon lter is to clean the air in the room. Carbon lters should be cleaned regularly and replaced within every 3 to 6

months in accordance with your frequency of use.

* Clean the surface of your device using a damp piece of cloth and a non-abrasive detergent. Do not, under any circumstances, clean it using

abrasive substances like vitriol or bleachers or rough pieces of sponge.

* The lighting system is designed to be used while cooking. It should not be used to illuminate the room for prolonged periods. This might damage

the lighting equipment.

E-FILTERS

Aluminum cartridge lters are used in all of our products in order to capture oil particles sucked along with food vapor before they enter the

device. These lters vary in size and type in accordacne with the product series and types. They are easy to remove and reassenble. They can

washed in hand without applyinh pressure or impacts using natural detergents and they can be washed in dish washers as well. Cleaning lters

once in every 2 to 3 months in accordance with frequency of use is crtitical for both re safety and device efciency.

More sensitive optional YKF A, AC, B, C, E, F and YKAF-A type carbon lters can also be used in all of our products in accordance with product

series and types in order to evacuate oil particles in the air and odour in special cases where the indoor air cannot be evacuated. Carbon lters

should be replaced in every 3 to 6 months in accordance with stove and cooking systems. Type YKF A, AC,C, E : After locating the carbon lter

on the lugs at both sides of the plastic engine body, turn it 90° (a quarter turn) and the assembly will be completed when you hear the ‘click’

sound. Retrace these steps to disassemble it (Figure E, H). Type YKF-B, F: This should be located in front of the metal box in which the engine kit

is located. Locate the lugs under the lter on the holes on the surface of the box which faces the wall and nish the assembly by pushing the clips

on the upper section of the lter towards the inside of the box (Figure F). If the engine is located inside a metal box in your product, then type A,

AC, C, E carbon lters are convenient for your product. Type A carbon lters are used for ush ventilation hoods. In case you need YALF and

YKF lters, they can be purchased from the authorized service provider or our company after selecting your lter from the gures in subsection 3

of the Technical Section.

F- CONTROLLER TYPES AND USE

Controller types which vary depending on your product model are described below. You can determine the controller type for your product by

checking the product code section of Article H.

1- TYPE TC -

It was designed with 5 rotation speeds. It is used for T2004-1 and T2004 engines.

M.On/Off Button: It turns the engine on and off. The engine will start at the 3nd cycle at startup.

(minus) Button: This is the rotation speed reduction button. You reduce rotation speed by keeping this button pressed. The minimum rotation

speed is 1.

(plus) Button: This is the button for increasing rotation speed. You can incerase rotation speed by keeping this button pressed. The maximum

rotation speed is 5.

Turbo Timer Button: When you press the Turbo Timer button, the engine will operate at the highest rotation speed and it will be programmed

for automatic shutdown after 5 minutes. The motor operation will revert to normal if you press ROTATION- or ROTATION+ when the turbo

timer is on but the timer will continue. When the times is on, the timer led will be on and automatic shutdown will initiate after 5 minutes. The

state of the led light will not change though. The engine will shut down if the timer button is pressed when the timer is on.

The Light Button: This button is for turning the Light/Led on and off. If you briey press it, the light will be turned on and if you keep it pressed

for 3 seconds, the led light will be turned on. The led light and lighting system can be turned on at the same time and they can also operate

separately.

Filter Warning: ‘C’ (Clean or Change) warning will be displayed on the indicator after the engine reaches 60 hours of operation. This requires

the user to clean or replace the lter (in accordance with your lter type). Keep the (-) button pressed until ‘E’ (Erased) is displayed on the

indicator (for about 5 seconds) in order to reset the lter time.

Instruction Manual

For the ventilation hood;

* Drill the holes as shown in Figure G1 and G2 inside your closet according to the template provided with the product.

* Place the device inside the closet and x it using the m4x40 screws that come with the device.

* Connect the 100 mm exible pipe provided by the user to the the ue ap and ensure air discharge.
