Ubiquiti EdgeRouter POE [3/20] Introduction
![Ubiquiti EdgeRouter POE [3/20] Introduction](/views2/1072899/page3/bg3.png)
1
Introduction
Introduction
Thank you for purchasing the Ubiquiti Networks
™
EdgeRouter
™
PoE
5-Port Router, which is part of the EdgeMAX
™
platform. For more
information, visit www.ubnt.com/edgemax
This Quick Start Guide is designed to guide you through
the installation and show you how to access the EdgeOS
™
Configuration Interface. This Quick Start Guide also includes the
warranty terms, and is for use with the EdgeRouter PoE, model
ERPoe-5.
Package Contents
EdgeRouter PoE Power Adapter
(24V, 2.5A)
Power Cord
5-Port Power over Ethernet
Router
Model: ERPoe-5
M2.9x20 Screws
(Qty. 2)
M2.9 Anchors
(Qty. 2)
Quick Start Guide
TERMS OF USE: All Ethernet cabling runs must use CAT5 (or above). It is the customer’s responsibility to
follow local country regulations, including operation within legal frequency channels, output power,
indoor cabling requirements, and Dynamic Frequency Selection (DFS) requirements.
