![Icom IC-A210 [18/40] Clearing the memory contents](/views2/1074157/page18/bg12.png)
14
3
MEMORY OPERATION
■
History memory channel
The transceiver has 10 history memory channels.
The standby frequency is stored into a history memory chan-
nel when pushing [↔].
The frequency is stored into the history memory channel in
order from “CH01” to “CH10.”
q Push [RCL] to enter the memory mode.
• The channel number appears.
• The memory channel name also appears if it has been entered.
w Rotate [O-DIAL] to select the history memory channel.
• “HISTORY” appears.
e Rotate [DIAL] to select a desired channel.
• Push [↔] to exchange the history memory channel frequency to
the active frequency if necessary.
r Push [RCL] to exit the memory mode.
■
Clearing the memory contents
(Regular and group memory
channels only)
Unwanted memory channels can be cleared.
q Push [RCL] to select memory mode.
• The channel number appears.
• The memory channel name also appears if it has been entered.
w Rotate [O-DIAL] to select the memory channel type.
• Select from regular memory channel or group memory channel.
e Push [MEM] again, then rotate [O-DIAL] to select
“DELETE.”
• The memory channel number blinks.
r Push [MEM] to delete the memory channel data.
•“-- -- -- -- -- --” appears momentarily, then the next selectable
channel appears.
t Push [RCL] to exit the memory mode.
CH01
127.005
122.00
RX
HISTORY
CH01
127.000
127.000
122.00
RX
MEMORY
ÅDELETE Ç
CH01
122.00
RX
MEMORY
IC-A210.qxd 2007.07.24 2:06 PM Page 14
