Icom IC-A210 [33/40] Cloning
![Icom IC-A210 [33/40] Cloning](/views2/1074157/page33/bg21.png)
29
7
CLONING
D Data cloning
Cloning allows you to quickly and easily transfer the
programmed contents or data from a PC to a transceiver
using the optional CS-A210
CLONING SOFTWARE.
Data can be cloned to and from a PC (IBM compatible) using
the optional CS-A210 CLONING SOFTWARE and the optional OPC-
1529R
CLONING CABLE (connect with the data jack). Consult the
CS-A210 instruction manual and HELP file for details.
D Displayed Message
• While clone writing.
• When clone writing is finished properly.
• When clone writing error occurs.
• While clone reading.
• When turn the power OFF/ON after clone writing error oc-
curs.
(The transceiver boots with Error mode.)
In this case, Clone writing correctly data to the transceiver is
necessary to cancel the error.
CLONE
WRITE
CLONE
WRITE OK
CLONE
WRITE ERR
CLONE
READ
127.00
RX
MEMORY
CLONE
NO DATA
06
07
IC-A210.qxd 2007.07.24 2:06 PM Page 29
