Icom IC-A210 [9/40] Basic operation
![Icom IC-A210 [9/40] Basic operation](/views2/1074157/page9/bg9.png)
5
2
BASIC OPERATION
01
02
■ Frequency selection
IC-A210 has 2 ways to select the desired frequency.
ï General frequency selection
Select the desired frequency which is used for the next oper-
ating frequency in the standby frequency indicator. Then ex-
change the active frequency for the standby frequency.
NOTE: Operate from “Standby frequency selection
(Step 1-2)” to “Frequency exchanging (Step 2-2)” as pgs. 5–6.
ï Direct frequency selection
The desired frequency direct selection is available.
Refer to “Direct frequency selection mode operation.”
■ Standby frequency selection
(Step 1-2)
q Rotate [VOL] clockwise to turn power ON.
• Previously used frequencies appear in the active and
standby frequency indicators.
w Rotate [DIAL] and [O-DIAL] to select the desired fre-
quency to the standby frequency.
• The active frequency is not affected.
• Rotate [O-DIAL] to set above 1 MHz digit.
• Rotate [DIAL] to set below 100 kHz digit.
•Set the frequency step* in the menu mode, if necessary (p. 27).
*Available for depending on versions.
TIP: For quick frequency setting, often used frequencies
can be programmed into memory channels. Refer to “MEM-
ORY OPERATION” (pgs. 9–18).
When a memory channel is recalled, the previous standby
frequency is erased.
CAUTION:
DO NOT
turn the power ON until the aircraft engines have
been started. It is very important for protection of the power
supply circuit.
IC-A210.qxd 2007.07.24 2:06 PM Page 5
