SPECIFICATIONS
D General
• Frequency range : 118.000 to 136.975 MHz
161.650 to 163.275 MHz*
• Channel spacing : 25 kHz
• Frequency stability : ±5 ppm
• Operating temperature : –20˚C to +55˚C
–4˚F to +131˚F
• Antenna impedance : 50 Ω
• Number of memory channels : 10 memory channels
200 group channels
10 history channels
10 GPS channels
10 weather channels*
• Mode : AM (6K00A3E)
•Power supply requirement : 13.80 V / 27.50 V DC
(negative ground)
•Dimensions : 160 (W)✕ 34 (H)✕271 (D) mm
(projections not incl.)
6
5
/
16
(W)✕1
11
/
32
(H)✕10
21
/
32
(D)
in
• Weight : approx 1.0 kg; 2.2 lb
*U.S.A. version only, receiving only.
D Transmitter
• Mode : A3E
• Output power : 8 W (Carrier power)
• Spurious emissions : –60 dBc
• Microphone impedance : 600 Ω
• Modulation limiting : 70% (Max 98%)
D Receiver
• Receive system : Double conversion
superheterodyne
• Intermediate frequencies : 1st 38.85 MHz
2nd 450 kHz
•Sensitivity : (AM) Less than 2 µV (pd)
at 6 dB S/N
(FM) Less than 1.4 µV
at 12 dB SINAD*
• Selectivity : 6 dB ±3 kHz
60 dB ±22 kHz
• Spurious response rejc. : More than 74 dBµ
• Audio output power : 5 W with a 4 Ω load (External
speaker)
60 mW with a 500 Ω load
(Headphone)
Measurements made in accordance with RTCA DO-186B for
U.S.A. version. All stated specifications are subject to change
without notice or obligation.
