27
5
MENU MODE
■ MENU mode items (Continued)
D External Input Level “AUX LEVEL”
Set the external input level.
• OFF (0) : The external input does not operate.
• 001–080 : Setting the external input level from 1 to 80.
• AF GAIN : Interlocking with [VOL].
D Beep Tone Level “BEEP”
Confirmation beep tones normally sound when storing mem-
ory, operating time-out-timer function, etc. These can be set
the desired beep level as you prefer.
• OFF (0) : The beep tone turns OFF.
• 001–100 : Setting the beep tone level from 1 to 100.
D Intercom Usable Setting “INCOM MODE”
Set the intercom using or not.
• ON : The intercom is usable.
• OFF : The intercom is unusable.
D Time-Out-Timer “TIME OUT”
To prevent accidental prolonged transmission, etc., the trans-
ceiver has a time-out-timer function. This timer starts when a
transmission begins, and will cut off the transmission when
the time set in the timer elapses.
• 020–240 : Setting time-out-timer starting period from 20 sec. to
240 sec. at 10 sec. intervals.
D Memory Clear “MEM CLEAR”
Setting values in the CPU are cleared.
Push and hold [MEM] for 2 sec., the CPU is reset as follow.
• MENU : MENU mode items are reset.
• MEMORY : Stored memories are reset.
• ALL : All CPU data is reset.
05
IC-A210.qxd 2007.07.24 2:06 PM Page 27
