PANEL DESCRIPTION

ROAM REQUEST KEY

➥ Push to return to the home site.

➥ Push and hold to start roaming.

SITE LOCK KEY

Push to turn the Site Lock function ON and OFF.

This function inhibits automatic roaming, and can be useful

when the transceiver is out of the communication area such

as on a subway or in an elevator.

EMERGENCY KEY

Push and hold for the specified time period to select the

emergency channel and automatically send a DTMF emer-

gency signal once or repeatedly.

SCRAMBLER KEY

Push to toggle the scrambler function ON or OFF.

COMPANDER KEY

Push to turn the compander function ON and OFF.

The compander function reduces noise components from

the transmitted audio to provide clear communication.

USER SET MODE KEY

Push for 1 sec. to enter the User set mode.

The User set mode allows you to set seldom-changed set-

tings.

Push this key momentarily in the User set mode to select

the function, and push [CH Up] or [CH Down] to change the

setting.

SIREN KEY

Push to emit a siren. This function can be used for situations

such as a security alarm for example.

SELECT MODE KEY

(available for Passport/LTR only)

Push to select the operating mode from System or Talk

Group.

• System channel and talk group selection

q Push [Select Mode] to select the operating mode from

System or Talk Group.

w Then push [UP] or [DOWN] to select the desired system

channel or talk group, in sequence.
