CONVENTIONALOPERATION

D DTMF receiving and transmitting

—Optional UT-108 is required—

If the transceiver has [Send DTMF] assigned to it, a

DTMF encode channel is displayed when pushed, and as-

signed DTMF encode channels can be selected via [UP] or

[DOWN].

Receiving:

q Push [UP] or [DOWN], or rotate [ROTARY SELECTOR]

to select the conventional system channel, in sequence.

w Push [Select call] to mute the channel. (“

”appears)

eWhenreceivingacall,abeepisemittedandmuteisre-

leased. (“

”disappears)

Transmitting:

q Push [UP] or [DOWN], or rotate [ROTARY SELECTOR]

to select the conventional system channel, in sequence.

w Push [Send DTMF]— a DTMF encode channel appears.

e Push [UP] or [DOWN] to select the desired DTMF en-

code channel.

r Push [PTT] to transmit the selected DTMF code in the

selected DTMF channel.

 •Push[P0] to cancel the DTMF transmission.

■ User set mode

If the transceiver has [User Set Mode] assigned to it, you

can“customize”thetransceiveroperationtosuityourprefer-

ences and operating style.

Entering the user set mode:

q Push and hold [User Set Mode] to enter user set mode.

Push [User Set Mode] momentarily to select the item.

Then push [UP] or [DOWN] to set the desired level/condi-

tion.

Available set mode functions:

 •Backlight :ON,AutoorOFF

 •Ringer :ONorOFF

 •Beep :ONorOFF

 •SQLLevel :0to255

 •MicGain :1to5

 •BatteryVoltage :ONorOFF

 •SystemInformation :ONorOFF

 •Run-Time :Thetransceiver’srunningtimeis

displayed.

w Push and hold [User Set Mode] to exit user set mode.
