BASIC OPERATION

■ Power ON

☞ NOTE: Charge the battery pack before turning power on

for the ﬁrst time (pgs. 6–8)

Push and hold [PWR] for 1 sec. to turn power on.

• Current battery voltage may be dis-

played for 2 sec.

• The display shows the approx. volt-

age in 0.5 V steps.

• If “OVER V” appears, UNPLUG the

external DC plug immediately. Con-

nected voltage is over 16 V and could

damage the transceiver.

■ Setting a frequency

D Via the keypad

(from the MHz digits)

➀ Push [VFO] to select VFO

mode.

➁ Push digit keys correspond-

ing to the desired frequency.

• When inputting a frequency in

the 50 or 1200 MHz bands, it

is necessary to input the deci-

mal point.

• When a digit is mistakenly

input, push [VFO] and input

from the beginning.

• When an unacceptable fre-

quency is input, the display re-

verts to the previously

displayed frequency.

•“0,” “2,” “5” and “7” are accept-

able as the 1 kHz digit input

depending on the 10 kHz digit.

for 1 sec.

after

PWR

2 sec.

[Example]
