Icom IC-T81A [26/40] Scan functions
![Icom IC-T81A [26/40] Scan functions](/views2/1074452/page26/bg1a.png)
22
8
SCAN FUNCTIONS
■ Scan types
FULL SCAN (p. 23)
Band
edge
Band
edge
Scan
Jump
PROGRAMMED SCAN (p. 23)
Scan
Jump
Band
edge
Band
edge
Scan edges
MEMORY SCAN (p. 23
Mch 1
Mch 0
Mch 2 Mch 3
Mch 4
Mch 5
Mch 6Mch 99
N
o
t
y
e
t
p
r
o
g
r
a
m
m
e
d
MEMORY SKIP SCAN (p. 23)
Mch 1
Mch 0
Mch 2 Mch 3
Mch 4
Mch 5
Mch 6Mch 99
S
K
I
P
N
o
t
y
e
t
p
r
o
g
r
a
m
m
e
d
☞ NOTE: Push [MULTI(↔)] during full/programmed scan to
change the band being scanned or to select a different pair
of scan edges.
Push [MULTI(
↔)] during memory (skip) scan to change the
memory channel groups: 1.2 GHz, VHF, UHF, 50 MHz, air
band or WFM programmed memories; or, all programmed
memories.
Repeatedly scans all fre-
quencies over a selected
band.
Repeatedly scans all pro-
grammed memory chan-
nels.
Repeatedly scans be-
tween two user-pro-
grammed frequencies.
Used for checking for fre-
quencies within a speci-
fied range such as
repeater output frequen-
cies.
Repeatedly scans all
memories, except those
set as skip channels.
IC-T81A/E Manual-(1) 01.12.5 6:55 PM Page 22 (1,1)
