32
6
DSC OPERATION
■ Received messages
The transceiver automatically stores up to 20 distress mes-
sages and 20 other messages. The messages can be used
as an assistance to the logbook.
q Push
[
[
DSC/ENT
DSC/ENT
]
] to select the DSC menu.
w Rotate
[
[
CHANNEL
CHANNEL
]
] to select “RCV Calls,” push
[
[
DSC/ENT
DSC/ENT
]
].
DD
Distress message
q Rotate
[
[
CHANNEL
CHANNEL
]
] to select “Distress,” push
[
[
DSC/ENT
DSC/ENT
]
].
w Rotate
[
[
CHANNEL
CHANNEL
]
] to scroll to the desired message,
push
[
[
DSC/ENT
DSC/ENT
]
].
•When some messages are blinking, the messages have not
been read.
e Rotate
[
[
CHANNEL
CHANNEL
]
] to scroll the message.
r Push
[
[
DSC/ENT
DSC/ENT
]
] to exit the DSC menu or push
[
[
HI/LO
HI/LO
]
]
to clear the displayed message and returns to the normal
operation.
ToClear
ThisData
No[DSC/ENT]
Yes[H/L]
Distress
<123123123
Explosion
UTC:12:48
32°43.212N
123°45.221W
ToClear
ThisData
No[DSC/ENT]
Yes[H/L]
SelDTRSMSG
˘123123123
111222345
Chuck 3
SelMessege
˘Distress
Other
SelItem
˘RCVCalls
DTRSSet
Setup
