47
9
CONNECTIONS AND MAINTENANCE
■ Dimensions
145.0 (5
23
⁄32)
165.0 (6
1
⁄2)
31.4
(1
1
⁄4)
53.0
(2
3
⁄32)
Unit: mm (inch)
110.0 (4
11
⁄32) 109.4 (4
5
⁄16)
9
