7 | Application guidelines
Installer reference guide
53
EJHA04AAV3 + EHY2KOMB28+32AA
Daikin Altherma H Hybrid
4P531180-1B – 2020.02
7.4.5 DHW pump for disinfection
Setup
f
g e
h d
a cb
a Outdoor unit
b Gas boiler
c Tank
d Cold water
e Shower
f Domestic hot water pump
g Heater element
h Non-return valve
▪ The DHW pump is field-supplied and its installation is the responsibility of the
installer. For the electrical wiring, see "To connect the domestic hot water
pump"[499].
▪ If using a third-party DHW tank of which the specifications are lower than those
of a dedicated tank, the temperature of the DHW tank must be set to maximum
60°C. If applicable legislation requires higher temperature for disinfection,
connect a DHW pump and heater element as shown above.
▪ If applicable legislation requires disinfection of the water piping until the tapping
point, you can connect a DHW pump and heater element (if needed) as shown
above.
Configuration
The outdoor unit can control DHW pump operation. For more information, see
"10Configuration"[4124].
7.5 Setting up the energy metering
▪ Via the user interface, you can read out the following energy data:
- Consumed energy (electricity)
- Consumed gas (only in case of EHY2KOMB28+32AA gas boiler)
▪ You can read out the energy data:
- For space heating
- For domestic hot water production
▪ You can read out the energy data:
- Per month
- Per year
INFORMATION
The calculated consumed energy (electricity) and consumed gas are estimations, the
accuracy cannot be guaranteed.
