Daikin EHY2KOMB32AA — руководство по установке и эксплуатации газового котла [24/48]
![Daikin EHY2KOMB32AA [24/48] Installation](/views2/1746844/page24/bg18.png)
6 Installation
Installation and operation manual
24
EHY2KOMB28+32AA
Daikin Altherma H Hybrid – Gas boiler module
4P538953-1A – 2020.02
Which fixation position to use
a
b
a In case of fixation to a pipe
b In case of fixation to a sleeve
Maximum distance between clamps
Vertical position of pipe Other position of pipe
2000mm 1000mm
▪ Divide the length between the brackets evenly.
▪ Every system MUST contain at least 1 bracket.
▪ Position the first clamp at a maximum of 500 mm from the
gasboiler.
≤1000 mm
≤2000 mm
≤1000 mm
≤250 mm
≤250 mm
≤250 mm
≤250 mm
≥3° (50 mm/m)
≤1000 mm
≤1000 mm
≤500 mm
a
b
a Second clamp after the second elbow
b First clamp after the second elbow
