4 About the box
Installation and operation manual
8
EHY2KOMB28+32AA
Daikin Altherma H Hybrid – Gas boiler module
4P538953-1A – 2020.02
4 About the box
4.1 Gas boiler
4.1.1 Symbols on the package
This is a fragile piece of equipment: Please provide a dry
storage space for the unit.
This is a fragile piece of equipment: Please be very careful
not to drop.
Store the unit in a flat position as indicated on the box.
No more than 5 boxes should be stacked on top of each
other.
MAX. 2
When stacking 6 boxes on one pallet, no more than 2
pallets should be stacked on top of each other.
MAX. 3
When stacking 4 boxes on one pallet, no more than 3
pallets should be stacked on top of each other.
4.1.2 To unpack the gas boiler
Before unpacking, move the gas boiler as close as possible to its
installation position.
1
2
WARNING
Tear apart and throw away plastic packaging bags so that
nobody, especially children, can play with them. Possible
risk: suffocation.
4.1.3 To remove the accessories from the gas
boiler
1 Remove the accessories.
a
b
c d
a b c d
a Mounting strip
b Condensate trap
c Installation and operation manual
d Current loop module, cable and installation manual
