SPECIFICATIONS AND UNPACKING
3
11
•Frequency coverage (MHz):
U.S.A. 000.010000–823.999999*
849.000001–868.999999
894.000001–1300.000000
Europe 000.010000–1300.000000*
*Specifications guaranteed 0.5–1300 MHz only.
•Receive system : Triple superheterodyne
•Mode : WFM, FM, AM, SSB, CW
•Frequency stability : ±3 ppm at 1300 MHz
(0°C to +50°C; 32°F to +122°F)
•Frequency resolution :1 Hz (minimum)
•Power supply :13.8 V DC ±15 % for receiver
requirement unit; or, supplied AC adapter
(negative ground)
•Current drain (at 13.8 V DC):
Power ON (PC power OFF) 0.1 A
Max. audio 0.7 A
Standby (squelched) 0.6 A
•Usable temp. range : 0°C to +50°C; +32°F to +122°F
•Intermediate frequencies:
1st 266.7 MHz
2nd 10.7 MHz
3rd 450 kHz (except WFM)
•Receive sensitivity (typical)*:
*When 230 kHz (for WFM), 15 kHz (for FM), 6 kHz (for AM) and
2.8 kHz (for SSB/CW) passband widths are selected.
•Squelch sensitivity (threshold):
Frequency
(MHz)
SSB/CW
(10 dB S/N)
AM
(10 dB S/N)
FM
(12 dB SINAD)
WFM
(12 dB SINAD)
0.5–1.799999 0.56 µV 2.5 µV
—
—
1.8–27.99999
0.28 µV 1.4 µV
30–49.99999 0.35 µV 1.8 µV
50–699.99999 0.2 µV 1.0 µV 0.32 µV 0.79 µV
700–1300 0.25 µV 1.3 µV 0.4 µV 1.0 µV
28–29.99999
0.5 µV
Frequency
(MHz)
SSB/CW AM FM WFM
0.5–1.799999 14 µV 1.8 µV
—
—
1.8–27.99999
7.1 µV 0.89 µV
30–49.99999
50–699.99999 5.6 µV 0.71 µV 0.5 µV 5.6 µV
700–1300 7.1 µV 0.89 µV 0.63 µV 7.1 µV
28–29.99999
0.63 µV
