Icom IC-PCR1000 [2/16] Features
![Icom IC-PCR1000 [2/16] Features](/views2/1074686/page2/bg2.png)
i
IMPORTANT
READ ALL INSTRUCTIONSand on-line help care-
fully and completely before using the receiver.
SAVE THIS INSTRUCTION MANUAL— This
instruction manual contains important operating instructions
for the IC-PCR1000 COMMUNICATIONS RECEIVER FOR
COMPUTER.
USEantenna(s), such as a well-matched 50 Ω antenna and
feedline. For radio communications, the antenna is of critical
importance, along with sensitivity.
SYSTEM REQUIREMENTS
•IBM PC compatible computer
•An RS-232C serial port
(38400 bps or faster)
•Microsoft
®
Windows
®
95 or Microsoft
®
Windows
®
3.1 with
appropriate DOS
•Intel i486DX4 processor or faster
(Pentium® 100 MHz or faster
recommended)
•At least 16 MB RAM
•At least 10 MB of hard disk space
•640 ✕ 480 pixel display
(800 ✕ 600 pixel display recommended)
FEATURES
•USER-SELECTABLE INTERFACE
Users can choose from 3 different operating screens de-
pending on their ability level and preference.
•WIDE FREQUENCY RANGE, MULTI-MODE RECEIVE
The IC-PCR1000 has a wide frequency coverage from 0.5
MHz to 1300 MHz* with all mode receive capability.
*Some frequency ranges are restricted depending on version.
•IF SHIFT
The IF shift function is effective in SSB mode for reducing in-
terference from nearby signals. It does so by electronically
shifting the passband of the IF filter.
•REAL-TIME BANDSCOPE FUNCTION
The real-time bandscope function makes it easy to find busy
frequencies and also easy to observe receive frequency band
conditions. The maximum band width is ±200 kHz.
•NOISE BLANKER •VSC (Voice Scan Control) FUNCTION
•S-METER SQUELCH •HIGH PERFORMANCE PLL
CIRCUIT •A VARIETY OF TUNING STEPS •A VARIETY OF
SCANS •DIGITAL AFC CIRCUIT
Versions of the IC-PCR1000 which display “CE” on the serial
number seal, comply with the essential requirements of the
89/336/EEC directive for Electromagnetic Compatibility.
