7. Wasserableitrinne reinigen
①
Öffnen Sie die Abdeckung des Reinigungskopfs und nehmen Sie den Schmutzsammelbehälter
heraus Drehen Sie dann den Reinigungskopf um und nehmen die Reinigungsrolle heraus
②
Die herausnehmbare Ableitrinne befindet sich unten am Gehäuseboden Ziehen Sie sie mit
dem Spezialhaken vorsichtig heraus Entfernen Sie dann den schwarzen Filterschwamm, der
sich in der Ableitrinne befindet
③
Reinigen Sie die Ableitrinne mit sauberem Wasser, das Sie gegebenenfalls auch mit einer
Reinigungslösung versetzen können
④
Setzen Sie den Filterschwamm am linken Ende der Ableitrinne wieder ein (nicht auf der Seite
des Reinigungsrollenmotors)
⑤
Setzen Sie die Ableitrinne wieder ordnungsgemäß in das Gehäuse ein Achten Sie dabei
darauf, dass die Positionierlöcher der Ableitrinne mit dem Gerätekörper übereinstimmen
Drücken Sie dann die Ableitrinne vorsichtig von links nach rechts, um zu prüfen, ob sie
ordnungsgemäß befestigt ist und beide Enden der Ableitrinne bündig abschließen
⑥
Führen Sie zum Schluss die verbleibenden Installationsschritte durch
8. Filterschwamm reinigen/ersetzen
①
Nehmen Sie die Wasserableitrinne heraus (siehe Abschnitt „Wasserableitrinne reinigen“)
②
Reinigen/ersetzen Sie den Filterschwamm
Hinweis: Der Filterschwamm ist an der linken Seite der Ableitrinne einzusetzen Er dient
der Steigerung der Reinigungsleistung Es wird empfohlen, den Filterschwamm alle 2 Wochen
auszutauschen
③
Setzen Sie die Wasserableitrinne wieder ein (siehe Abschnitt „Wasserableitrinne reinigen“)
④
Führen Sie zum Schluss die verbleibenden Installationsschritte durch
Lagern & Transportieren
1. Gerät lagern
①
Schalten Sie das Gerät vor der Lagerung aus, verriegeln Sie den Gerätekörper und setzen Sie
ihn auf die Ladestation
②
Reinigen Sie vor der Lagerung die Innenseite des Reinigungskopfs, um die Vermehrung von
Bakterien zu vermeiden
③
Achten Sie vor der Lagerung darauf, dass die Wasserbehälter leer sind
④
Wenn das Gerät über eine Woche außer Betrieb ist, ziehen Sie das Netzanschlusskabel ab,
bauen die Reinigungswalze aus und lagern Sie sie nach dem Trocknen
Hinweis: Lagern Sie das Gerät nicht über längere Zeit ohne Ladestation direkt auf Holzboden,
um eine mögliche Beschädigung Ihres Bodens zu vermeiden
Nach der Reinigung das Gerät und Zubehörteile gut trocknen lassen Stehendes Schmutzwasser und
feuchte Bauteile begünstigen die Vermehrung von Bakterien, Pilzen und Gerüchen
2. Gerät transportieren
①
Sorgen Sie dafür, dass das Gerät ausgeschaltet und in senkrechter Position verriegelt ist
②
Sie können das Gerät an der Aussparung zum Anheben auf der Rückseite des Geräts
transportieren und anheben oder nach hinten lehnen Die Laufrollen erleichtern den Transport
Hinweis: Wenn Sand oder ein scharfer Gegenstand auf dem Boden liegt, betreiben Sie das
Gerät nicht, damit mögliche Kratzer vermieden werden
12
4 Place back the ltering sponge at the left end (the further
position from the cleaning roller motor) of the water sink.
2 You can move and uplift the appliance by the hand lifting
position at the appliance’ s back; or lean it backward, the
auxiliary wheels will help for easy moving.
1 Switch off the appliance, lock it in upright position.
2 Open the cleaning head cover, press the square buckle at
the lateral side to take out the brush roller (Maximum open angle
of the drive motor is 30°. Please use appropriate strength and
method to avoid any damage).
3 Insert a new cleaning roller onto the motor, push and x it
into the cleaning head till the lateral button in place.
To insert a new cleaning roller, please refer to 2 Assembling.
If you want to continue to benet from the best cleaning results,
make sure you always use original HIZERO brush roller, and we
recommend you to replace it every six months.
5 Place the water sink back correctly, making sure the
positioning holes on the water sink match rightly with the
machine body, then slightly press the water sink from left to right
to check if it is xed well, and lastly make both ends of the water
sink ush.
6 Finish the rest installation steps.
5.8 Cleaning/Replacing the ltering sponge
1 Take out the water sink (refer to the Section 5.6).
1 Before storage, switch off the appliance, lock the body and
place it onto the charging base.
1 Make sure the appliance is switched off and locked in upright
position.
2 Please clean the inside of the cleaning head before storing
to avoid bacteria breeding.
3 Before storage, please make sure the water tanks are empty.
4 If the appliance will be out of service for above one week,
please unplug the power cord, remove the cleaning roller and
store it after drying.
2 Clean/Replace the ltering sponge.
3 Put back the water sink (refer to the Section 5.6).
4 Finish the rest installation steps.
Note: The ltering sponge should be placed at the left end of the
water sink to improve the cleaning efciency, and it is suggested
to replace the ltering sponge every 2 weeks.
Note: If there is sand or sharp object on the oor, do not operate
the appliance to avoid any possible scratch.
Note: Do not store the appliance directly on wooden oor without
charging base for a long time to avoid any possible damage of
your oor.
Note: The maximum open angle of the drive motor is 30°. Please
operate it carefully.
6 Storing & Moving
7 Replacing
6.1 Storing
7.1 Replacing the Brush Roller
6.2 Moving
1
2
3
30º
4 5
6 7
11
3 As per the following gures, hang the cleaning roller above
the oor, make the appliance continuously operate in Mode 2
until clean water runs out.
4 Steps 1 to 3 could be repeated for two to three times to
achieve better cleaning effects.
Note: Make sure the appliance won’ t topple over when hanged
above the oor.
Note: empty the dirty water tank before aforementioned steps.
Method 2
1 Refer to 7.2 Replacing the Cleaning Roller to dismantle the
cleaning roller for cleaning.
1
2
5.5 Cleaning the Trash Container
5.7 Cleaning the Water Sink
5.6 Cleaning the Cleaning Head Cover
1 Take out the trash container, then empty and wash it under
the tap. The cleaning brush can be used to sweep off the trash.
Let it dry before reassembling.
1 Open the cleaning head cover, take out the trash tray, then
turn the cleaning head over and take out the cleaning roller.
2 Find the removable water sink in the groove of the bottom
shell, gently pull out with the special hook, then remove the
black ltering sponge placed in the water sink.
3 Clean the water sink with clean water, and it is ne to add
some daily cleaning solvent if necessary.
1 Open the cleaning head cover, press the release button to
take it out, then remove the brush roller.
1
2
2 Clean the cover with a soft damp cloth.
3 Reinstall the brush roll into the cover, then x the cover back
to the cleaning head.
1 2
1
2
3
11
3 As per the following gures, hang the cleaning roller above
the oor, make the appliance continuously operate in Mode 2
until clean water runs out.
4 Steps 1 to 3 could be repeated for two to three times to
achieve better cleaning effects.
Note: Make sure the appliance won’ t topple over when hanged
above the oor.
Note: empty the dirty water tank before aforementioned steps.
Method 2
1 Refer to 7.2 Replacing the Cleaning Roller to dismantle the
cleaning roller for cleaning.
1
2
5.5 Cleaning the Trash Container
5.7 Cleaning the Water Sink
5.6 Cleaning the Cleaning Head Cover
1 Take out the trash container, then empty and wash it under
the tap. The cleaning brush can be used to sweep off the trash.
Let it dry before reassembling.
1 Open the cleaning head cover, take out the trash tray, then
turn the cleaning head over and take out the cleaning roller.
2 Find the removable water sink in the groove of the bottom
shell, gently pull out with the special hook, then remove the
black ltering sponge placed in the water sink.
3 Clean the water sink with clean water, and it is ne to add
some daily cleaning solvent if necessary.
1 Open the cleaning head cover, press the release button to
take it out, then remove the brush roller.
1
2
2 Clean the cover with a soft damp cloth.
3 Reinstall the brush roll into the cover, then x the cover back
to the cleaning head.
1 2
1
2
3
12
4 Place back the ltering sponge at the left end (the further
position from the cleaning roller motor) of the water sink.
2 You can move and uplift the appliance by the hand lifting
position at the appliance’ s back; or lean it backward, the
auxiliary wheels will help for easy moving.
1 Switch off the appliance, lock it in upright position.
2 Open the cleaning head cover, press the square buckle at
the lateral side to take out the brush roller (Maximum open angle
of the drive motor is 30°. Please use appropriate strength and
method to avoid any damage).
3 Insert a new cleaning roller onto the motor, push and x it
into the cleaning head till the lateral button in place.
To insert a new cleaning roller, please refer to 2 Assembling.
If you want to continue to benet from the best cleaning results,
make sure you always use original HIZERO brush roller, and we
recommend you to replace it every six months.
5 Place the water sink back correctly, making sure the
positioning holes on the water sink match rightly with the
machine body, then slightly press the water sink from left to right
to check if it is xed well, and lastly make both ends of the water
sink ush.
6 Finish the rest installation steps.
5.8 Cleaning/Replacing the ltering sponge
1 Take out the water sink (refer to the Section 5.6).
1 Before storage, switch off the appliance, lock the body and
place it onto the charging base.
1 Make sure the appliance is switched off and locked in upright
position.
2 Please clean the inside of the cleaning head before storing
to avoid bacteria breeding.
3 Before storage, please make sure the water tanks are empty.
4 If the appliance will be out of service for above one week,
please unplug the power cord, remove the cleaning roller and
store it after drying.
2 Clean/Replace the ltering sponge.
3 Put back the water sink (refer to the Section 5.6).
4 Finish the rest installation steps.
Note: The ltering sponge should be placed at the left end of the
water sink to improve the cleaning efciency, and it is suggested
to replace the ltering sponge every 2 weeks.
Note: If there is sand or sharp object on the oor, do not operate
the appliance to avoid any possible scratch.
Note: Do not store the appliance directly on wooden oor without
charging base for a long time to avoid any possible damage of
your oor.
Note: The maximum open angle of the drive motor is 30°. Please
operate it carefully.
6 Storing & Moving
7 Replacing
6.1 Storing
7.1 Replacing the Brush Roller
6.2 Moving
1
2
3
30º
4 5
6 7
12
