ENGLISH
11
ENG
Pull the plug out of the plug socket before any
adjustments or servicing are performed.
Ensure that the spot where you wish to work is free
of
power cables, gas lines or water pipes
(e.g. using a metal detector).
Avoid inadvertent starts by always unlocking the
switch when the plug is removed from the mains
socket or in case of a power cut.
Keep hands away from the rotating tool!
Remove chips and similar material only with the
machine at standstill.
High forces are released if the tool jams or catches.
Always hold the tool firmly, ensure you have good
footing and concentrate when working.
Secure small workpieces. Clamp in a vice for
example.
Dust from material such as paint containing lead,
some wood species, minerals and metal may be
harmful. Contact with or inhalation of the dust may
cause allergic reactions and/or respiratory
diseases to the operator or bystanders.
Certain kinds of dust are classified as carcinogenic
such as oak and beech dust especially in conjunc-
tion with additives for wood conditioning (chromate,
wood preservative). Material containing asbestos
must only be treated by specialists.
- Where the use of a dust extraction device is
possible it shall be used.
- The work place must be well ventilated.
- The use of a dust mask of filter class P2 is
recommended.
Follow national requirements for the materials you
want to work with.
See page 3 (please unfold).
1
Additional handle
2Depth stop
3 Slide switch for drilling/impact drilling
4 Rocker switch for pulse function *
5 Locking button (continuous activation)
6 Scaffold hook mounting
7 Trigger switch
8 Rotational speed preselection wheel
9 Rotation selector switch
10 Geared chuck *
11 Chuck key (for a geared chuck) *
12 Keyless chuck Futuro Plus *
* equipment-dependent
SBE 610 and SBE 610 Impuls
• Fatigue-free work thanks to light weight
• Aluminium cast gear housing for optimised heat
dissipation and stability
• User-friendly routing of machine exhaust air in
every working situation
SBE 610 Impuls
• Optional pulse mode for precise fastening and
convenient drilling.
Before plugging in, check to see that the
rated mains voltage and mains frequency,
as stated on the rating label, match with
your power supply.
To guarantee secure purchase of the
chuck:
After initial drilling (clockwise),
use a screwdriver to firmly tighten the safety
screw inside the drill chuck. Caution left-handed
thread! (see Section 8.9)
7.1 Assembly of the additional handle
For safety reasons, always use the
additional handle supplied.
Open the clamping ring by turning the additional
handle (1) counter-clockwise. Push the additional
handle onto the collar of the machine. Insert the
depth stop (2). Securely tighten the additional
handle at the angle required for the application.
8.1 Depth Stop Setting
Loosen the additional handle (1). Set depth stop (2)
to the desired drilling depth and retighten addi-
tional handle.
8.2 Switching On and Off
To start the machine, press the trigger switch (7).
The rotational speed can be changed at the trigger
switch by pressing.
For continuous operation the trigger switch can be
locked using the lock button (5). To stop the
machine, press the trigger switch again.
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore, always hold the machine
with both hands using the handles provided,
stand in a safe position and concentrate.
5Overview
6 Special Product Features
7 Commissioning
8Use
17026872_0108 SBE 610.book Seite 11 Dienstag, 29. Januar 2008 11:20 11
