ENGLISH
13
ENG
In the case of deep bores pull the drill bit out of the
bore from time to time in order to remove the bore
dust or shavings.
Drill tiles and other brittle materials without impact.
Switch on the pulse function (SBE 610 Impuls) for
drilling without centring.
The chuck can be removed for screwdriving. Insert
screwdriver bit directly in the hexagon socket of the
spindle.
If a bit spring collet
(as accessories: order no.
6.31281)
is fitted, the screwdriver bit is held in posi-
tion.
Keyless chuck cleaning:
After prolonged use hold the chuck vertically, with
the opening facing down, and fully open and close
it several times. The dust collected falls from the
opening. Regular use of cleaning spray on the jaws
and jaw openings is recommended.
f
Use only genuine Metabo accessories.
If you need any accessories, check with your
dealer.
For dealers to select the correct accessory, they
need to know the exact model designation of your
power tool.
See page 4.
A Angle drilling and screwdriving attachment
B Flexible shaft
C Drill stand
D Machine vice
E Scaffolding hook with integrated bit depot:
Clip into the
scaffolding hook fastening (6)
and turn to engage in one of the 4 positions.
F Steel wire end brush
G Steel wire cup brush
H Steel wire rotary brush
I Bit clamping bush
For complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out by
qualified electricians ONLY!
The connection cable must only be replaced
by Metabo or an authorised customer service
workshop.
Any Metabo power tool in need of repair can be
sent to one of the addresses listed in the spare
parts list.
Please enclose a description of the fault with the
power tool.
Metabo's packaging can be 100% recycled.
Scrap power tools and accessories contain large
amounts of valuable resources and plastics that
can be recycled.
These instructions are printed on chlorine-free
bleached paper.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline
2002/96/EC on used electronic and
electric equipment and its implementation in
national legal systems, used power tools must be
collected separately and handed in for
environmentally compatible recycling.
Explanatory notes on the specifications on page 2.
Changes due to technological progress reserved.
P
1
= Nominal power input
P2 = Power output
n
0
= No load speed
n
1
= Speed at rated load
dia. max= Max. solid drill diameter
s max = Max. impact rate
b = Chuck capacity
G = Spindle thread
H = Drill spindle with hexagon socket
m = Weight without mains cable
D = Collar diameter
Vibration total value (vector sum of three
directions) determined in accordance with
EN 60745:
a
h, ID
= Vibration emission value
(impact drilling into concrete)
a
h, D
= Vibration emission value
(drilling into metal)
K
h,ID
,K
h,D
= Unsafe (vibration)
9 Tips and Tricks
10 Maintenance
11 Accessories
12 Repairs
13 Environmental Protection
14 Technical Specifications
