English

DESCRIPTION:

1. Cold water tank

2. Cup warmer

3. \

4. Steam/hot water knob (on the right side)

5. Filter holder retaining ring

6. Steam/hot water arm

7. Removable water drainage tray

8. Filter holder

9. Single cup filter

10. Two cup filter

11. On/off switch (on the right side)

12. \

13. Coffee/hot water/steam lever switch

14. Indicator light: machine ready

15. Coffee press/tamper

16. Measuring spoon

17. Manometer

18. Filter for pods

19. Removable water tank cover

20. Water level indicator

21. PID temperature control

22. Pump lever switch

USER INSTRUCTIONS:

Starting of the machine:

1. Remove the machine from its packing and make sure all packing parts have been taken off (including the

protection bags).

2. Lay the machine on a flat and steady surface far away from hot places and from the water taps.

3. Remove the water tank cover (19) on the top of the machine and take out the water tank (1) paying attention

not to damage the water tubes inside the tank.

4. Fill the tank (1) with cold water.

5. Replace the water tank back in the machine and check that the water tubes are not bent and that the filter is

well set on one of them; reposition the tank cover (19).

6. Plug in the machine in the mains. Make sure that the wall socket has the right voltage.

7. Place the filter holder (8) under the brewing group (5) and turn it from the left to the right. Leave it there so

that it can get warm and it gets ready for use.

8. Turn the machine on by pushing the on /off switch (11). The indicator light of the switch (11) comes on to

confirm the power supply.

9. Open the steam/hot water knob (4).

10. Position the lever switch (13) on coffee mode and press the pump switch (22).

11. When water comes out of the steam nozzle (6), let down the pump switch (22) and close the steam/hot water

knob (4).

12. After completing all these operations, leave the machine on.

13. The PID (21) will visualize the degrees inside the boiler and will control the boiler’s heating.

14. The PID is already set from the producer on 95°C, i.e. the ideal temperature for a good cup of coffee. (If you

want to change the PID’s temperature, please follow the instructions written under How to set the

temperature inside the boiler by means of the PID).

Preparing an espresso:

15. Check that the water tank (1) has been filled in with water by looking at the water level indicator (20).

16. Press the on/off switch (11): the indicator light of the switch (11) will come on. Do this operation only if the

machine is off. If it’s on pass to the following point.

17. As soon as the PID’s display shows the set temperature and the indicator light (14) remains on, the machine is

ready for use.

18. Fit the single cup filter (9) or the two cup filter (10) into the filter holder (8) that has been warmed up by

leaving it attached to the brewing group as described in point 7.

19. Fill the filter with ground coffee by means of the supplied measure spoon (16): 1+ ½ measuring spoonful (16)

= 1 coffee cup - 3 measuring spoonful (16) = 2 coffee cups. Every time you fill the filter with a spoonful of

coffee, press the coffee with the coffee press/tamper (15) before proceeding to fill it with the next spoonful

and make sure that there are no coffee rests on the filter border.

20. Insert the filter holder (8) in the brewing group ring (5), turn it from left to right with force, then put the cup

on the removable water drainage tray (7).

21. Position the lever switch (13) on coffee mode and lift up the pump switch (22). The manometer (17) will show

the reached pressure, between 8 and 14 bar.

22. Once you get the desired quantity of coffee, push down the switch (22) again.

23. Remove the filter holder (8) and throw away the coffee grounds. Make sure that the filter holder is clean and

reposition it in the brewing group to warm up again.

Preparing an espresso with the use of coffee pods:

24. Check that the water tank (1) has been filled in with water by looking at the water level indicator (20).

25. Press the on/off switch (11): the indicator light of the switch (11) will come on. Do this operation only if the

machine is off. If it’s on pass to the following point.

26. As soon as the PID’s display shows the set temperature and the indicator light (14)remains on, the machine is

ready for use.
