ESiEN09-06 Combination Table
General Information 5
2. Combination Table
Heat pump
P: Pair: Combination depending on AHU heat exchanger volume and capacity.
Saturated suction temperature (SST) = 6°C, SH (superheat) = 5 K, air temperature = 27°C DB /
19°C WB.
Note: If conflicting result occurs, capacity selection has priority over volume.
Control box Expansion valve kit
Outdoor unit EKEQDCBV3 EKEQFCBV3 EKEXV63 EKEXV80 EKEXV100 EKEXV125 EKEXV140 EKEXV200 EKEXV250
three
phase
ERQ125 P P P P P P P - -
ERQ200P P --PPPPP
ERQ250 P P - - - P P P P
Allowed heat exchanger volume (dm
3
) Allowed heat exchanger capacity (kW)
EKEXV class Minimum Maximum Minimum Maximum
63 1.66 2.08 6.3 7.8
80 2.09 2.64 7.9 9.9
100 2.65 3.3 10 12.3
125 3.31 4.12 12.4 15.4
140 4.13 4.62 15.5 17.6
200 4.63 6.6 17.7 24.6
250 6.61 8.25 24.7 30.8
ESiEN09-06.pdf 13 2/16/2010 4:42:25 PM
