ESiEN09-06 Special Control
Function 31
3.2.2 Oil Return Operation in Heating Operation
Outdoor Unit Actuator
Oil return preparation
operation
Oil return operation Post-oil-return operation
Compressor Upper limit control 176 Hz + ON + ON
124 Hz + OFF + OFF
2-steps increase/20sec.
till Pc - Pe>0.4 MPa
Outdoor unit fan
STEP7
or
STEP8
OFF STEP8
Four way valve ON OFF ON
Main motorized valve (EV1) SH control → 480 pls 480 pls 55 pls
Subcooling motorized valve (EV2) SH control 0 pls 0 pls
Hot gas bypass valve (SVP) OFF OFF OFF
Accumulator oil return valve (SVO) ON ON ON
Injection (SVT) (RXYQ5P model only)
OFF OFF OFF
Ending conditions 170 sec.
• 4 min.
• Ts - Te<5°C
• 10 sec.
• Pc - Pe>0.4MPa
or
or
AHU actuator Heating oil return operation
Fan
Thermostat ON unit Field setting
Stopping unit OFF
ESiEN09-06.pdf 39 2/16/2010 4:42:32 PM
