ESiEN09-06 Special Control
Function 33
3.4 Pump-down Residual Operation
3.4.1 Pump-down Residual Operation in Cooling Operation
If the liquid refrigerant stays in the Evaporator at the startup of a compressor, this liquid refrigerant enters the
compressor, thus resulting in diluted oil in the compressor and then degraded lubrication performance.
Consequently, in order to recover the refrigerant in the Evaporator while the compressor stops, the pump-down residual
operation is conducted.
3.4.2 Pump-down Residual Operation in Heating Operation
Actuator Master unit operation
Compressor 124 Hz + OFF + OFF
Outdoor unit fan Fan control
Four way valve OFF
Main motorized valve (EV1) 480 pls
Subcooling motorized valve (EV2) 0 pls
Hot gas bypass valve (SVP) OFF
Accumulator oil return valve (SVO) ON
Ending conditions 5 min.
Actuator Master unit operation
Compressor 124 Hz + OFF + OFF
Outdoor unit fan STEP7
Four way valve ON
Main motorized valve (EV1) 0 pls
Subcooling motorized valve (EV2) 0 pls
Hot gas bypass valve (SVP) OFF
Accumulator oil return valve (SVO) ON
Ending conditions 3 min.
ESiEN09-06.pdf 41 2/16/2010 4:42:32 PM
