ESiEN09-06 Troubleshooting by Indication on the Remote Control
Troubleshooting 231
3.35 “
LC
” Outdoor Unit: Malfunction of Transmission
Between Inverter and Control PC Board
Remote Control
Display
LC
Applicable
Models
ERQ 125 ~ 250 A7W1
Method of
Malfunction
Detection
Check the communication state between inverter PC board and control PC board by micro-
computer.
Malfunction
Decision
Conditions
When the correct communication is not conducted in certain period.
Supposed
Causes
Malfunction of connection between the inverter PC board and outdoor control PC board
Defect of outdoor control PC board (transmission section)
Defect of inverter PC board
Defect of noise filter
Faulty fan inverter
Incorrect type of fan inverter
Faulty compressor
Faulty fan motor
ESiEN09-06.pdf 239 2/16/2010 4:42:55 PM
