Specifications ESiEN09-06
8 Specifications
1. Specifications
1.1 Outdoor Units
Heat Pump 50Hz Standard Series ERQ 125/200/250 A7W1B
TECHNICAL SPECIFICATIONS ERQ125A7W1B ERQ200A7W1B ERQ250A7W1B
Nominal
capacity
Cooling kW 14,0 22,4 28,0
Heating kW 16,0 25,0 31,5
COP Cooling 3,98 4,29 3,77
Heating 4,004,504,09
Capacity range HP 5 8 10
Nominal input Cooling kW 3,52 5,22 7,42
HeatingkW4,005,567,70
PED category 2
Casing Colour Daikin white
Material Painted galvanised steel
Dimensions Unit Height mm 1680
Width mm 635 930
Depth mm 765
Packing Height mm 1855
Width mm 796 1055
Depth mm 860
Weight Unit kg 159 187 240
Packed unit kg 182 217 273
Packing
information
Carton kg 3,8 4,02
Wood kg 19,15 20,85
Plastic kg 0,215 0,265
Heat
exchanger
Specifications Length mm 1483 1778
Nr of rows 54
Fin pitch 2
Nr of passes 8 18
Face area m² 1,762 2,112
Nr of stages 2
Empty tubeplate
hole
0
Tube type HI-XSS (8)
Fin Type Non-symmetric waffle louvre
Treatment Hydrophylic and anti corrosion resistant
Fan Type Propeller
Quantity 1
Air flow rate
(nominal at
230V)
Cooling m³/min 95 171 185
Heating m³/min
95 171 185
External static pressure Pa 78 Pa in high static pressure
Discharge direction Vertical
Motor Quantity 1
Model Brushless DC
Speed rpm
Output W 350 750
Speed
(nominal)
Cooling
rpm
Speed
(nominal)
Heating
rpm
Compressor Quantity 1 2
Motor Quantity 1
Model Inverter
Speed rpm 6300 7980 6300
Motor
output
kW
2,8 3,8 1,2
Type Hermetically sealed scroll compressor
Crankcase
heater
W
33
Quantity 0 1
Model ON - OFF
Speed rpm 2900
Motor
output
kW
4,5
Type Hermetically sealed scroll compressor
Crankcase
heater
W
33
ESiEN09-06.pdf 16 2/16/2010 4:42:25 PM
