ESiEN09-06 Troubleshooting by Indication on the Remote Control
Troubleshooting 197
3.11 “
CJ
” AHU: Malfunction of Thermostat Sensor in Remote
Control
Remote Control
Display
CJ
Applicable
Models
AII AHU models
Method of
Malfunction
Detection
Malfunction detection is carried out by temperature detected by remote control air temperature
thermistor. (Note:)
Malfunction
Decision
Conditions
When the remote control air temperature thermistor becomes disconnected or shorted while the
unit is running.
Supposed
Causes
Defect of remote control thermistor
Defect of remote control PC board
Troubleshooting
Note: In case of remote control thermistor malfunction, unit is still operable by suction air thermistor on
AHU.
∗ Refer to “Thermistor Resistance / Temperature Characteristics” table on P270.
Clear the malfunction code
history. (While in inspection
mode,
press and hold the
“ON/OFF”
button for a period of
five seconds or more.)
YES
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
(V2787)
NO
Is "CJ"
displayed on the remote
control?
Replace remote control.
External factor other than
equipment malfunction.
(for example, noise etc.)
ESiEN09-06.pdf 205 2/16/2010 4:42:52 PM
