37
DEFRNLITESPTNOSVDAPLSKHUHRCS EN
0478 121 9917 D - EN
Installing electric cable:
● Insert electric cable (1) in strain relief
moulding (2) of handlebar console as
illustrated. Make sure the cable tie (3) is
correctly positioned in the strain relief
moulding.
● Press electric cable (1) into holder (4)
on quick-release clamp body. The
electrical cable must lie taught against
the handlebar tube in the area of the
lower handlebar.
7.3 Installing dual handlebar
(ME 339)
Installing upper handlebar:
● Insert flat head bolt (J) through cable
guide (K) and attach electric cable (1).
● Fit dual handlebar (2) onto both lower
handlebar sections (3). Insert flat head
bolts (J) – on right with cable guide (K),
on left without – through bores from the
inside to the outside and tighten with
rotary handles (L).
Installing cable clip:
● Fasten electric cable (1) to upper
handlebar with cable clip (M). Ensure a
distance of 25 - 27 cm between cable
clip and switch on upper handlebar.
7.4 Assembling grass catcher
box
● Fit upper part of grass catcher
box (B) onto lower part of grass catcher
box (C). Ensure correct position in
guides (1).
● Push pin (D) through bores provided
from inside.
● Allow upper part of grass catcher
box (B) to engage in lower part of grass
catcher box using slight pressure.
● Attach grass catcher box (Ö 8.3).
8.1 Mono handlebar (ME 339 C)
The ME 339 C lawn mower is
equipped with an adjustable
telescopic handlebar.
1 Folding down handlebar:
Transport position (for cleaning, for
space-saving transport and for storage of
the machine):
● Set handlebar to minimum height.
● Hold handlebar (1) with one hand and
open quick-clamping device (2).
● Fold down handlebar (1) forwards.
● If necessary, quick-clamping device (2)
can be closed and the handlebar set to
the transport position.
Working position (to push machine):
Danger of electric shock!
In order to prevent damage to the
insulating layer on the handlebar,
only press on the cable clips by
hand. Do not use any tools (e.g.
hammer or screwdriver).
5
6
8. Controls
Danger of electric shock!
The electric cable must always be
attached to the quick-release clamp
body and the handlebar console.
Some slack must be retained at the
adjustment area of the telescopic
handlebar at maximum handlebar
length (Ö 7.2).
Danger of pinching!
The handlebar can fold down or
retract when the quick-clamping
device is released. For this reason,
always hold the handlebar (1) with
one hand at its highest point when
you open the quick clamping
device.
7
