3
3 EN
FROST FREE COMBIS
CONTROL PANEL
Open the top door of the fridge in order to access the control panel.
Turn on the knob to switch on the appliance and set the temperature of the freezer compartment and Fridge. (Recommended setting – 2-3).
Turn the knob to “0” to turn off the appliance.
The orange light comes on when the thermostat knob is turned
to SUPER. In this case the compressor continues to function
as normal.
FREEZING
(Figure 1)
The preservation of frozen foods is guaranteed in all of the freezer’s compartments.
During maximum capacity of the freezer, it is advised to remove the drawers and to place the food directly on the shelves for optimal freezing.
In some products there is a
section in the top part, (see quick guide).
Place the foods to be frozen in the
drawer, turn the thermostat clock-wise to SUPER position, and the orange light will come on (see figure 1).
After 24 hours, freezing is completed. Therefore, reset the thermostat to position 2-3. The SUPER function is automatically disabled
from the circuit board after 26 hours.
The rating plate states the maximum quantity of foods that can be frozen, (see figure 2).
N.B. For better air circulation, leave some room in between the foods and avoid blocking the cooling air outlets.
DEFROSTING
(Figure 2)
A small amount of frost or drops of water on the back of the freezer compartment when
the freezer is working is normal.
Make sure the water outlet is always clean. Make sure foods do not touch the back or
sides of the freezer compartment.
The freezer compartment does not need to be defrosted because this product is equipped
with an automatic system which prevents frost from being formed (frost free).
Important: If the room temperature is very warm, the appliance may work continuously and a layer of frost will deposit on
the back of the fridge compartment. In this case, turn the knob to lower settings (1-2).
The green “ON” light shows that the unit is working. This light
is on irrespective of the knob setting, except for when the
knob is set to 0.
Important: Some appliances will start to function at least 6 minutes after the plug has been connected to the power supply outlet and the
temperature has been set.
NB. This is the rating plate. If you need to contact our Service Department in the
event of faults, remember to give them the information on the plate.
A
Place the appliance on the floor or at a 45° angle,
as it is necessary to work on the bottom of the
appliance.
Remove the lower plinth by pulling out the 3
protective plugs and by loosening the screws.
Drill the plinth on the marked left hand-side area.
REVERSING THE OPENING OF THE DOORS
In order to reverse the opening of the doors, follow the indications in relation to the insert and hinge type your product is made up of.
