1-4
Chapter 1: Product Introduction
Chapter 1
1.1.3 Central Processing Unit (CPU)
ThemotherboardcomeswithanAM4socketdesignedforAMDRyzen™2ndGeneration/
Ryzen™1stGeneration/Ryzen™withRadeon™VegaGraphicsProcessors.
STRIX B450-I GAMING
ROG STRIX B450-I GAMING CPU AM4
EnsurethatallpowercablesareunpluggedbeforeinstallingtheCPU.
TheAM4sockethasadifferentpinoutdesign.EnsurethatyouuseaCPUdesignedforthe
AM4socket.TheCPUtsinonlyonecorrectorientation.DONOTforcetheCPUintothe
sockettopreventbendingtheconnectorsonthesocketanddamagingtheCPU!
E14337_ROG_STRIX_B450-I_GAMING_UM.indb 4 2018-06-15 18:28:26
