ROG STRIX B450-I GAMING
1-5
Chapter 1
1.1.4 System memory
Themotherboardcomeswithtwo(2)DoubleDataRate4(DDR4)DualInlineMemory
Modules(DIMM)slots.
ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.DONOT
installaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.
STRIX B450-I GAMING
ROG STRIX B450-I GAMING 288-pin DDR4 DIMM socket
Recommended memory configurations
E14337_ROG_STRIX_B450-I_GAMING_UM.indb 5 2018-06-15 18:28:26
