Asus ROG STRIX B450-I GAMING [43/92] Front i o connector

ROG STRIX B450-I GAMING

2-9

Chapter 2

2.1.7 Front I/O connector

USB 2.0

AAFP

To install USB 2.0 connector

To install front panel audio connector

USB 3.1 Gen 1

To install USB 3.1 Gen 1 connector

To install the front panel connector

E14337_ROG_STRIX_B450-I_GAMING_UM.indb 9 2018-06-15 18:28:35
