ROG STRIX B450-I GAMING
1-17
Chapter 1
9. Fan and pump connectors (4-pin CPU_FAN; 4-pin AIO_PUMP; 4-pin CHA_FAN)
Connectthefancablestothefanconnectorsonthemotherboard,ensuringthatthe
blackwireofeachcablematchesthegroundpinoftheconnector.
• DONOTforgettoconnectthefancablestothefanconnectors.Insufcientairow
insidethesystemmaydamagethemotherboardcomponents.Thesearenotjumpers!
Donotplacejumpercapsonthefanconnectors!
• Ensuretofullyinsertthe4-pinCPUfancabletotheCPUfanconnector.
• TheCPU_FANconnectorsupportstheCPUfanofmaximum (24W)fanpower.2A
• Connectthepumpcablefromtheall-in-onecooler(AIOcooler)totheAIO_PUMP
header,andconnectthefancablestotheCPU_FANandCHA_FANheaders.
ROG STRIX B450-I GAMING Fan connectors
STRIX B450-I GAMING
10. Thermal sensor connector (2-pin T_SENSOR)
Thisconnectorisforthethermistorcablethatallowsyoutomonitorthetemperatureof
yourmotherboard’scriticalcomponentsandconnecteddevices.
STRIX B450-I GAMING
ROG STRIX B450-I GAMING T_SENSOR connector
