1.1.6 Jumper

1. Clear RTC RAM (2-pin CLRTC)

ThisjumperallowsyoutocleartheRealTimeClock(RTC)RAMinCMOS.Youcan

cleartheCMOSmemoryofdate,time,andsystemsetupparametersbyerasingthe

CMOSRTCRAMdata.TheonboardbuttoncellbatterypowerstheRAMdatain

CMOS,whichincludesystemsetupinformationsuchassystempasswords.

ToerasetheRTCRAM:

1. TurnOFFthecomputerandunplugthepowercord.

2. Useametalobjectsuchasascrewdrivertoshortthetwopins.

3. PlugthepowercordandturnONthecomputer.

4. Holddownthe<Del>keyduringthebootprocessandenterBIOSsetuptore-

enterdata.

ExceptwhenclearingtheRTCRAM,neverplaceametalobjectontheCLRTCjumper.

Placingametalobjectwillcausesystembootfailure!

Ifthestepsabovedonothelp,removetheonboardbatteryandplaceametalobjectagain

tocleartheCMOSRTCRAMdata.AftertheCMOSclearance,reinstallthebattery.

STRIX B450-I GAMING

ROG STRIX B450-I GAMING Clear RTC RAM jumper
