Daikin 5MXS90E7V3B [2/73] 1 technical specifications
![Daikin 5MXS90E7V3B [2/73] 1 technical specifications](/views2/1770263/page2/bg2.png)
3
1
2
• Split Sky Air • Outdoor Units 2
• Outdoor Units • R410A • MXS-DAVMB_E2V1B_E7V3B
2 Specifications
2-1 TECHNICAL SPECIFICATIONS
2MXS4 0DAVMB 2MXS52E2V1B 3MXS52E2V1B 4MXS68E2V1B 4MXS80E7V3B 5MXS90E7V3B
Casing Colour Ivory White
Dimensions Unit Height mm 640 735 735 735 770 770
Width mm 685 936 936 936 900 900
Depth mm 285 300 300 300 320 320
Packing Height mm 676 797 797 784 900 900
Width mm 800 992 992 992 925 925
Depth mm 366 390 390 390 390 390
Weight Unit kg 39 49 49 59 72 73
Packed Unit kg 42 56 56 65 80 80
Heat
Exchanger
Dimensions Length mm 678 845 845 845 860 860
Nr of Rows 1 2 2 2 2 2
Fin Pitch mm 1.4 1.80 1.80 1.60 1.40 1.40
Nr of Stages 28 32 32 32 34 34
Tube type Hi-Xa(8) ø7.94 grooved
tubes 24
ø7.94 grooved
tubes 24
Hi-Xa(8) Hi-XSS(8) Hi-XSS(8)
Fin Type WF fin Colgate fin Colgate fin WF fin WF fin WF fin
Treatment Anti-corrosion
treatment (PE)
Anti-corrosion
treatment (PE)
Anti-corrosion
treatment (PE)
Anti-corrosion
treatment (PE)
Fan Type Propeller
Quantity 1 1 1 1 1 1
Air Flow Rate
(nominal at
230V)
Cooling m³/min 35 45.0 45.0 51.0 54.5 54.5
Heating m³/min 32 45.0 45.0 47.6 46.0
Motor Quantity 1 1 1 1 1 1
Model D50E-28 KFD-380-50-8A KFD-380-50-8A KFD-380-53-8C KFD-280-66-8A KFD-280-66-8A
Motor Speed
(nominal)
Cooling rpm 880 720 720 790 860
Heating rpm 880 720 790
Fan Motor Output W 50 53 53 53 66 66
Compressor Quantity 1 1 1 1 1
Motor Model 1YC23GXD 2YC36BXD 2YC36BXD 2YC45BXD 2YC63BXD#C 2YC63BXD#C
Type Hermetically sealed swing compressor
Motor
Output
W 600 1100 1100 1380 1920 1920
Operation
Range
Cooling Min °CDB 10 -10.0 -10.0 -10.0 -10.0 -10.0
Max °CDB 46 46.0 46.0 46.0 46.0 46.0
Heating Min °CWB -10 -15 -15 -15 -15 -15
Max °CWB 15.5 15.5 15.5 15.5 15.5 15.5
Sound Level
(nominal)
Cooling Sound
Power
dBA 62 59.0 59.0 61.0 62.0 66.0
Sound
Pressure
dBA 47 46.0 46.0 48.0 48.0 52.0
Heating Sound
Pressure
dBA 48 47.0 47.0 49.0 49.0 52.0
Sound Level
(Night quiet)
Sound Pressure dBA 43
Refrigerant Type R-410A
Charge kg 1.20 2.0 2.0 2.6 3.0 3.0
Refrigerant Oil Type FVC50K
Charged Volume l 0.40 0.65 0.65 0.75 0.75 0.75
