• Outdoor Units • R410A • MXS-DAVMB_E2V1B_E7V3B
1
2
• Split Sky Air • Outdoor Units3
2 Specifications
Piping
connections
Liquid (OD) Quantity 2 2 3 4 4 5
Diameter
(OD)
mm 6.35 6.35 6.35 6.35 6.35 6.35
Gas Quantity 2 2 2 2 1 2
Diameter
(OD)
mm 9.5 12.7 9.5 9.5 9.5 9.5
Quantity 1 2 1 1
Diameter
(OD)
mm 12.7 12.7 12.7 12.7
Quantity 2 2
Diameter
(OD)
mm 15.9 15.9
Drain Quantity 1
Diameter
(OD)
mm 18 18 18 18 25 25
Piping Length Minimum m 1.5 (for one room)
Maximum m 30 ( for total of
each room), 20
(for one room)
50 (for total of
each room)/25
(for one room)
50 (for total of
each room)/ 25
(for one room)
60 (for total of
each room)/ 25
(for one room)
70 (for total of
each room)/ 25
(for one room)
75 (for total of
each room)/ 25
(for one room)
Additional Refrigerant
Charge
kg/m 0.02/>20 0.02/>30m 0.02/>30m 0.02/>30m 0.02/>30m 0.02/>30m
Installation
height
difference
Maximum m 15(between
indoor unit and
outdoor unit)
15.0 (between
indoor unit and
outdoor unit)
15.0 (between
indoor unit and
outdoor unit)
15.0 (between
indoor unit and
outdoor unit)
15.0 (between
indoor unit and
outdoor unit)
15.0 (between
indoor unit and
outdoor unit)
Max. internunit level
difference
m 7.5 (between
indoor units)
7.5 (between
indoor units)
7.5 (between
indoor units)
7.5 (between
indoor units)
7.5 (between
indoor units)
7.5 (between
indoor units)
Heat Insulation Both liquid and gas pipes
Standard
Accessories
Item Installation manual
Quantity 1 pc 1 1 1 1 1
Item Screw bag Drain plug Drain plug Drain plug Drain plug Drain plug
Quantity 1 pc 1 1 1 1 1
Item Reducer
assembly
Reducer
assembly
Reducer
assembly
Reducer
assembly
Reducer
assembly
Quantity 1 1 1 1 1
Notes Nominal cooling capacities are based on : indoor temperature : 270CDB, 190CWB, outdoor temperature : 350CDB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 200CDB, outdoor temperature : 70CDB, 60CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m
Sound levels are measured in an anechoic room
Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings of this chapter.
The sound power level is an absolute value indicating the power which a sound source generates.
2-2 ELECTRICAL SPECIFICATIONS
2MXS40DAVMB 2 MXS52E2V1B 3MXS52E2V1B 4MXS68E2V1B 4MXS80E7V3B 5MXS90E7V3B
Power Supply Name VM V1 V1 V1 V3 V3
Phase 1 1 1 1 1 1
Frequency Hz 50/60 50 50 50 50 50
Voltage V 220-240/220-230 230 230 230 230 230
Voltage range Minimum V -10% -10% -10% -10% -10%
Maximum V +10% +10% +10% +10% +10%
Current Nominal
running current
(RLA)
Cooling
(A)
A 0.33 0.33 0.33 0.97 0.97
Heating
(A)
A 0.33 0.33 0.33 0.69
Starting current (cooling/
heating)
A 6.2 6.7 6.2 8.5 9.7 11.8
Z-max List No requirements
2-1 TECHNICAL SPECIFICATIONS
2MXS40DAVMB 2 MXS52E2V1B 3MXS52E2V1B 4MXS68E2V1B 4MXS80E7V3B 5MXS90E7V3B
