• Outdoor Units • R410A • MXS-DAVMB_E2V1B_E7V3B
1
3
• Split Sky Air • Outdoor Units5
3 Electrical data
Cooling (50Hz 230V)
Combination
Units
Power supply
Comp. OFM IFM
Hz Volts Min. Max. MCA MFA RLA W FLA W FLA
2.0
50 230 207 253
3.4
12
2.3
50 0.40
40 0.17
2.5 4.7 3.0 40 0.17
3.5 6.5 4.6 40 0.17
2.0+2.0 6.7 4.9 80 0.34
2.0+2.5 6.7 5.0 80 0.34
2.0+3.5 6.8 5.0 80 0.34
2.5+2.5 6.8 5.0 80 0.34
2.5+3.5 6.8 5.0 80 0.34
Heating (50Hz 230V)
Combination
Units
Power supply
Comp. OFM IFM
Hz Volts Min. Max. MCA MFA RLA W FLA W FLA
2.0
50 230 207 253
6.2
12
4.1
50 0.40
40 0.17
2.5 7.5 4.7 40 0.17
3.5 8.6 5.7 40 0.17
2.0+2.0 6.4 4.6 80 0.34
2.0+2.5 6.6 4.8 80 0.34
2.0+3.5 6.6 4.8 80 0.34
2.5+2.5 6.6 4.8 80 0.34
2.5+3.5 6.6 4.8 80 0.34
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Fan Motor Rated Output (W)
NOTES
1. RLA is based on the following conditions:
Power supply: 50Hz 240V
Cooling
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
Heating
Indoor temp.: 20°CDB
Outdoor temp.: 7°CDB/6°CWB
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker
5. For more details concerning conditional connections, see
http://eu.extranet.daikineurope.com, select ’’E-Data Books’’. Finally, click on the
document title of your choice.
