Asus ZenWiFi AX (XT8) [22/156] Monitoring your usb device

3.1.3 Monitoring your USB device

The ASUS Wireless Router provides a USB port for connecting a

USB device or a USB printer to allow you to share ﬁles and printer

with clients in your network.

NOTE: To use this feature, you need to plug a USB storage device, such

as a USB hard disk or a USB ash drive, to the USB 3.0 port on the rear

panel of your wireless router. Ensure that the USB storage device is

formatted and partitioned properly. Refer to the Plug-n-Share Disk

Support List at http://event.asus.com/networks/disksupport.
