6
1 Getting to know your wireless 1 Getting to know your wireless
routerrouter
NOTES:
• If any of the items are damaged or missing, contact ASUS for
technical inquiries and support. Refer to the ASUS Support Hotline
list at the back of this user manual.
• Keep the original packaging material in case you would need future
warranty services such as repair or replacement.
ZenWiFi AX Wireless Router Network cable (RJ-45)
Power adapter Quick Start Guide
1.1 Welcome!
Thank you for purchasing an ASUS ZenWiFi AX Wireless Router!
The ultra-thin and stylish ZenWiFi AX features a 2.4GHz, 5GHz-1,
and 5GHz-2 triple bands for an unmatched concurrent wireless
HD streaming; SMB server, UPnP AV server, and FTP server for 24/7
le sharing; a capability to handle 300,000 sessions; and the ASUS
Green Network Technology, which provides up to 70% power-
saving solution.
1.2 Package contents
