Candy CH63CT [10/84] Cleaning and maintenance
![Candy CH63CT [10/84] Cleaning and maintenance](/views2/1773103/page10/bga.png)
The locking function prevents the children from starting the hob.
It is also used for cleaning the control strip as the controls can be
locked without the hob being on.
To lock the hob :
- Press the on/off button .
- Press simultaneously " - " button and " + " button of the front
right zone (CH 633 front left zone), and then press again on
the " + " button of this zone. The hob is locked, the locking
indicator " L " is displayed on all zones for 20 seconds.
To unlock the hob :
- Press the on/off button . The locking indicator " L " is displayed
on all zones.
- Press simultaneously the " - " button and the " + " button of the
front right zone (CH 633 front left zone), and then press again
on the " - " button of this zone.
The hob is unlocked.
• LOCKING BUTTON OPERATION
• FAST HEATER OPERATION
Starting the fast heater
- Press the on/off button .
- Start the required zone, press the " + " button to obtain position
“9”, release the button briefly and press again the " + " button ;
the display alternates showing "A" “fast heater” and "9" heat
level.
- If necessary reduce to the required heat position, the display
alternates showing "A" “fast heater” and the new heat position.
Cooking
position
Power
released
(%)
Time of
fast heater
(minutes)
Maximum
operating
time before
automatic
cut off*
0 : 0 % : 0 : 0 H
1 : 3 % : 1 : 6 H
2 : 6 % : 3 : 6 H
3 : 11 % : 5 : 5 H
4 : 16 % : 6,5 : 5 H
5 : 19 % : 8,5 : 4 H
6 : 32 % : 2,5 : 1,5 H
7 : 45 % : 3,5 : 1,5 H
8 : 65 % : 4,5 : 1,5 H
9 : 100 % : 0 : 1,5 H
E.g. 1800 W zone at position 6 = 32% of 1800 W power released
When the “Fast heater” is on, the zone supplies 1800 W power
for 2.5 minutes, and adjusts to 576 W after this time.
* For increased safety, the cooking zones cut off automatically if
they are left on too long. The cut off depends on the heat level
used.
To desactivate the fast heater
- Switch on the cooking zone, press the " - " button to come back
to a normal heat level, decrease to the heat level required or to
" 0 " to stop the cooking zone.
NB:
Do not use a sponge which is too wet.
Never use a knife or a screwdriver.
A scraper with a razor blade will not damage the surface,
as long as it is kept at an angle of 30°.
Never leave a scraper with a razor blade within the reach
of children.
Never use abrasive products or scouring powders.
• The metal surround : to safely clean the metal surround wash
with soap and water, rinse, then dry with a soft cloth.
30° Maxi
• Before carrying out any maintenance work on the hob, allow it
to cool down.
• Only products, (creams and scrapers) specifically designed for
glass ceramic surfaces should be used. They are obtainable
from hardware stores.
• Avoid spillages, as anything which falls on to the hob surface
will quickly burn and will make cleaning more difficult.
• It is advisable to keep away from the hob all substances which
are liable to melt, such as plastic items, sugar, or sugar-based
products.
MAINTENANCE:
- Place a few drops of the specialised cleaning product on the
hob surface.
- Rub any stubborn stains with a soft cloth or with slightly damp
kitchen paper.
- Wipe with a soft cloth or dry kitchen paper until the surface is
clean.
If there are still some stubborn stains:
- Place a few more drops of specialised cleaning fluid on the
surface.
- Scrape with a scraper, holding it at an angle of 30° to the hob,
until the stains disappear.
- Wipe with a soft cloth or dry kitchen paper until the surface is
clean.
- Repeat the operation if necessary.
A FEW HINTS:
Frequent cleaning leaves a protective layer which is essential to
prevent scratches and wear. Make sure that the surface is clean
before using the hob again. To remove marks left by water, use
a few drops of white vinegar or lemon juice. Then wipe with
absorbent paper and a few drops of specialised cleaning fluid.
The control knobs can be removed for a complete cleaning.
However, you must care not to let any liquid go into the open
zones, and then to push the knobs fully on fitting back.
The glass ceramic surface will withstand scraping from flat-
bottomed cooking vessels, however, it is always better to lift them
when moving them from one zone to another.
8. CLEANING AND MAINTENANCE
9 GB-IE
