FDM40JEV1K - RD40JEY1K
Power Supply Cable
Interconnection cable
Outdoor unit
Terminal Block
Indoor unit
Terminal Block
Model Indoor FDM40JEV1K
Outdoor RD40JEY1K
Voltage range**
Indoor
220-240V/1Ph/50Hz+!
Outdoor
308-415V/3N~/50Hz+!
Power supply cable size* mm
2
Number of conductors
2.5
5
Interconnection cable size* mm
2
Number of conductors
2.5
4
Recommended time delay fuse* A 15
There must be an all pole disconnection
in the supply mains with a contact
separation of at least 3mm.
!
COMP
L
L
N
N
COMP
L
N
R
S
T
N
There must be an all pole disconnection
in the supply mains with a contact
separation of at least 3mm.
!
Model Indoor FDM40JEV1K
Outdoor RD40JEV1K
Voltage range**
Indoor
220-240V/1Ph/50Hz+!
Outdoor
220-240V/1Ph/50Hz+!
Power supply cable size* mm
2
Number of conductors
4.0
3
Interconnection cable size* mm
2
Number of conductors
2.5
4
Recommended time delay fuse* A 35
Interconnection cable
Outdoor unit
Terminal Block
Indoor unit
Terminal Block
FDM40JEV1K - RD40JEV1K
COMP
L
L
N
N
S
R
COMP
L
N
L
N
Power Supply Cable
