English
INSTALLATION DIAGRAM
Supply Duct
Air Intake
Wrap the insulated pipe with the
Þ nishing tape from bottom to top
Air Intake
Outdoor unit
Return Duct
Hanger
Air Discharge
Drain Piping
Thermal Insulation
Indoor unit
