INSTALLATION
MANUAL
Installation Manual
R22 Split Series
IM-CKE-0911(0)-DAIKIN(SASO)
Part No.: R08019037002
MODELS
FHC20JEVLK RD20JEVLK
FHC25JEVLK RD25JEVLK
FHC30JEVLK RD30JEVLK
FHC40JEVLK RD40JEVLK
FHC50JEVLK RD50JETLK
FHYC20JEVLK RYD20JEVLK
FHYC25JEVLK RYD25JEVLK
FHYC30JEVLK RYD30JEVLK
FHYC40JEVLK RYD40JEVLK
FHYC50JEVLK RYD50JETLK
R22 SPLIT SERIES
CVR-IM CKE-0911(0)DK(saso).indd 1 11/11/11 12:00:17 PM
Содержание
- Installation manual 1
- R22 split series 1
- English 3
- Indoor unit 3
- Outdoor unit 3
- Outline and dimensions 3
- Outdoor unit 4
- English 5
- Installation manual 5
- Safety precautions 5
- Warning caution 5
- For model fh y c20 25 30 40 50jevlk 6
- For model r y d20jevlk r y d25jevlk r y d30jevlk r y d40jevlk r y d50jetlk 6
- Important 6
- Be sure to read this manual before installing the air conditioner indoor unit voltage supply uctuation must not exceed 10 of rated voltage electricity supply lines must be independent of welding transformers which can cause high supply uctuation ensure that the location is convenient for wiring piping and drainage do not exert pressure on the resin parts when opening the unit or when moving it after opening do not move the unit from packaging while moving until it reaches the installation site use safe material or protection plates when unpacking it or lifting it to avoid damage or scratches to the unit 7
- English 7
- Indoor unit 7
- Installation diagram 7
- Installation of the indoor unit 7
- Outdoor unit 7
- Preliminary site survey 7
- Unit hanging 8
- Unit installation 8
- Drain piping work 9
- Drain test 9
- English 9
- Panel installation 9
- Grille lock cover must be installed as the gure below 10
- Grille lock cover the moving part protection for user direct touching 10
- If the unit need to be service steps below shall be followed con rm that the unit had been switched off before servicing the unit use screwdriver to unlock the screw on the grille lock cover remove the grille lock cover and open the intake grille for the service purpose install the intake grille and screw the grille lock cover after service and make sure the unit is proper install 10
- Install the front frame panel rmly to prevent cool air leakage which will cause condensation and water dripping 10
- English 11
- Figure a 11
- Figure b figure c 11
- Figure d figure e 11
- Wires installation 11
- Caution 12
- Installation of the outdoor unit 12
- A b c d 13
- All model 13
- Condensed water disposal of outdoor unit heat pump unit only 13
- English 13
- Installation clearance 13
- Maximum allowable pipe length and elevation 13
- Minimum distance mm 13
- Refrigerant piping 13
- Inch mm imperial wing nut type rigid clutch type 14
- Pipe size mm in torque nm ft lb 14
- Piping connection to the units 14
- Piping works and flaring technique 14
- Ø tube d a mm 14
- Electrical wiring connection 15
- English 15
- English 17
- English 19
- Charge operation 20
- Vacuuming and charging 20
- Vacuuming is necessary to eliminate all moisture and air from the system the series ii outdoor unit is provided with flare valve fittings 20
- Additional charge 21
- Caution 21
- English 21
- Caution 22
- Special precautions when charging unit with scroll compressors 22
- English 23
- Optional functions 23
- Possible direction for air discharge and air intake 23
- Possible opening dimension for duct connection 23
- Short duct speci cation 23
- Cooling heating 24
- Db dry bulb wb wet bulb 24
- Fault diagnosis 24
- For signal acceptance con rmation 24
- Indicator lights 24
- Note power led cool dry fan led turns on in these modes the unit will not detect sensor missing when the compressor is on call your dealer immediately when this error happen 24
- Operating range 24
- Wired controller if there is any abnormal condition detected wired controller will blink the error code 24
- Caution 25
- English 25
- Overall checking 25
- Phase protector optional 25
- Service and maintenance 25
- For any enquiries on spare parts please contact your authorized dealer if any malfunction of the air conditioner unit is noted immediately switch off the power supply to the unit check the following fault conditions and causes for some simple troubleshooting tips 26
- If the fault persists please call your local dealer serviceman 26
- Troubleshooting 26
- English 27
- Specifications 27
- Specifications 28
- English 29
- Specifications 29
