1-4
IMPORTANT
For model R(Y)D20JEVLK, R(Y)D25JEVLK, R(Y)D30JEVLK, R(Y)D40JEVLK & R(Y)D50JETLK:
1. After take off the bands, pull out the carton box from the top side of the unit.
* This product is not designed for re-packing. In case of re-packing, contact to Daikin Dealer.
C
K UN
K
E
E
P
BA
R
For model FH(Y)C20/25/30/40/50JEVLK:
Carton Box Top1)
Indoor Unit2)
Carton Box Bottom3)
UNPACKING
After take off the bands, lift the carton box
Lift the unit and remove the bottom carton.
1)
2)
EN CKE-0911(0)DK(saso).indd 4 12/6/11 3:05:08 PM
