![Daikin FHC40JEVLK [27/32] English](/views2/1785168/page27/bg1b.png)
1-25
English
MODEL INDOOR UNIT FHC20JEVLK FHC25JEVLK
OUTDOOR UNIT RD20JEVLK RD25JEVLK
RATED VOLTAGE V 220 220
RATED FREQUENCY Hz 60 60
COOLING (T1)
INDOOR
27DB
º
C/19WB
º
C
OUTDOOR
35DB
º
C/24WB
º
C
RATED CURRENT A 9.41 11.8
RATED POWER INPUT kW 2.06 2.59
CAPACITY Btu/h 19500 23300
kW 5.72 6.83
EER (Btu/h)/W 9.46 9.00
COOLING (T3)
INDOOR
29DB
º
C/19WB
º
C
OUTDOOR
46DB
º
C/24WB
º
C
RATED CURRENT A 10.7 13.4
RATED POWER INPUT kW 2.33 2.96
CAPACITY Btu/h 17100 21600
kW 5.01 6.33
EER (Btu/h)/W 7.33 7.29
NET WEIGHT INDOOR UNIT
kg
26 28
OUTDOOR UNIT
kg
49 57
REFRIGERANT R22
kg
1.60 1.80**
COUNTRY OF ORIGIN INDOOR UNIT
Malaysia
OUTDOOR UNIT
Malaysia
NOTE:
This product is not designed for repacking. In case of re-packing, contact to Daikin Dealer.
** Additional refrigerant charge of 0.2kg is needed in order to achieve the stated performance data.
MODEL INDOOR UNIT
FHYC20JEVLK FHYC25JEVLK
OUTDOOR UNIT RYD20JEVLK RYD25JEVLK
RATED VOLTAGE V 220 220
RATED FREQUENCY Hz 60 60
COOLING (T1)
INDOOR
27DB
º
C/19WB
º
C
OUTDOOR
35DB
º
C/24WB
º
C
RATED CURRENT A 9.41 11.8
RATED POWER INPUT kW 2.06 2.59
CAPACITY Btu/h 19500 23300
kW 5.72 6.83
EER (Btu/h)/W 9.46 9.00
COOLING (T3)
INDOOR
29DB
º
C/19WB
º
C
OUTDOOR
46DB
º
C/24WB
º
C
RATED CURRENT A 10.7 13.4
RATED POWER INPUT kW 2.33 2.96
CAPACITY Btu/h 17100 21600
kW 5.01 6.33
EER (Btu/h)/W 7.33 7.29
HEATING
INDOOR
20DB
º
C/--WB
º
C
OUTDOOR
7DB
º
C/6WB
º
C
RATED CURRENT A 8.22 10.5
RATED POWER INPUT kW 1.80 2.30
CAPACITY Btu/h 20000 24500
W 5.86 7.18
COP W/W 3.26 3.12
NET WEIGHT INDOOR UNIT
kg
26 28
OUTDOOR UNIT
kg
49 57
REFRIGERANT R22
kg
1.60 1.80**
COUNTRY OF ORIGIN INDOOR UNIT
Malaysia
OUTDOOR UNIT
Malaysia
SPECIFICATIONS
EN CKE-0911(0)DK(saso).indd 25 12/6/11 3:05:12 PM
