Daikin FHC25JEVLK [4/32] Outdoor unit
![Daikin FHC20JEVLK [4/32] Outdoor unit](/views2/1785168/page4/bg4.png)
1-2
Outdoor Unit
All dimensions are in mm
IJJ
D
M
E
B
G
O
Dimension
Model
ABCDEFGH I JKLMNO
R(Y)D40JEVLK
R(Y)D50JETLK
1030 826 400 410 57 72 90 40 746 142 60 26 448 22 28
NN
K
A
L
EF
H
C
EN CKE-0911(0)DK(saso).indd 2 12/6/11 3:05:07 PM
