Daikin FHC50JEV1K [5/24] English
![Daikin FHC50JEV1K [5/24] English](/views2/1784692/page5/bg5.png)
English
Outdoor Unit
All dimensions are in mm
A
M
N
P
D
K
L
E
F
B
R
G
U
Q
S
J
H
C
T
Dimension
Model
A B C D E F G H J K L M N P Q R S T U
RD40JEV1K
RD40JEY1K
RD50JEY1K
RD60JEY1K
1030 852 428 410 412 827 72 196 91 488 448 142 141 83 23 49 26 28 80
